Medium: water, hot water, air
Caliber: DN15-80
Pressure: 1.0-1.6mpa
Connection: thread
| Main parts and material | |
| Parts name | Material |
| Subject | Polarity rubber |
| Inside lining | Nylon burlap |
| Active joint | Forged cast iron |
| Function and specification | |
| Working pressure | 1.0(10) |
| Blasting pressure | 3.0(30) |
| Deflenction angle | 45 |
| Degrree of vacuum | 53.3(400) |
| Suitable temperature | ≤80 |
| Suitable medium | Water |
| Outline and connecting measurement | ||||||
| Type | DN | L | Axial displacement (mm) | lateral displacement | ||
| (mm) | (in) | (mm) | Elongation | Compression | (mm) | |
| JGD10-10 | 20 | 3/4 | 180 | 5-6 | 22 | 22 |
| 25 | 1 | 200 | 5-6 | 22 | 22 | |
| JGD12-10 | 32 | 1 1/4 | 225 | 5-6 | 22 | 22 |
| 40 | 1 1/2 | 225 | 5-6 | 22 | 22 | |
| 50 | 2 | 235 | 5-6 | 22 | 22 | |
| 65 | 2 1/2 | 245 | 5-6 | 22 | 22 | |
