P48H-16 Blow Down Valve

Medium temperature: ≤150 ℃

Medium: steam, water, oil

Caliber: DN25-50

Pressure: 1.6mpa

Body material: gray cast iron

Connection method: flange

Inquire Now Next Product

P48H-16 Blow Down Valve Material of main parts
Part Name		material
Body / bonnet		grey cast iron
Gears and racks		Ductile iron
Disc		2CR13

Sewage valve P48H-16 overall dimensions and connection dimensions
model	Nominal diameter (mm)	Size (mm)
model	Nominal diameter (mm)	L	D	D1	D2	bf	Z-φd
P48H-16	25	160	115	85	65	16-2	4-14
	32	180	135	100	78	16-2	4-18
	40	230	145	110	85	18-3	4-18
	50	250	160	125	100	18-3	4-18
