Medium: water
Use temperature: ≤80 ℃
Caliber: DN25-450
Pressure: 1.0-2.5MPa
Body material: cast iron
Connection method: flange
| Flux Control Valve 400X Material of main parts | ||||
| Part Name | material | |||
| Valve body | cast iron | |||
| Valve stem | Chrome stainless steel | |||
| Flow control valve 400X performance specification | |||||||||||
| model | Nominal pressure (mpa) | Test pressure (mpa) | proper temperature | Applicable medium | |||||||
| case | Sealed (water) | ||||||||||
| Flow control valve 400X | 1 1.6 2.5 | 1.5 2.4 3.75 | 1.1 1.76 2.75 | ≤80 ℃ | water | ||||||
| Flux Control Valve 400X Outline and connecting measurment | |||||||||||
| DN | 50 | 65 | 80 | 100 | 125 | 150 | 200 | 250 | 300 | 350 | 400 |
| L | 203 | 216 | 241 | 292 | 330 | 356 | 495 | 622 | 622 | 787 | 914 |
| H1 | 278 | 298 | 313 | 350 | 365 | 420 | 450 | 470 | 490 | 526 | 570 |
| H | 395 | 405 | 430 | 510 | 560 | 585 | 675 | 730 | 760 | 840 | 910 |
